| Feature | Value |
| Size | Midi Midi |
| Series | D |
| Mounting position | Vertical +/-5° |
| Design | Proportional standard mist lubricator Proportional standard mist lubricator |
| Max. oil capacity | 110 cm³ |
| Bowl guard | Metal bowl guard |
| Symbol | 00991532 |
| Operating pressure | 0 bar ... 16 bar |
| Min. flow rate for lubricator function | 8 l/min |
| Standard nominal flow rate | 6100 l/min |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] Inert gases |
| Note on operating and pilot medium | Lubricated operation not possible |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| Storage temperature | -10 °C ... 60 °C |
| Air purity class at output | Compressed air to ISO 8573-1:2010 [7:4:-] Inert gases |
| Media temperature | -10 °C ... 60 °C |
| Ambient temperature | -10 °C ... 60 °C |
| Product weight | 630 g |
| Type of mounting | With accessories |
| Pneumatic connection, port 1 | G1/2 |
| Pneumatic connection, port 2 | G1/2 |
| Note on materials | RoHS-compliant |
| Material bowl | PC |
1. We win with high quality.
Only with perfect quality system management can we have quality assurance. Fly Automation has passed ISO9001 quality management system certification.
Precision high-end testing equipment 100% inspection. Strive to be "100 points high quality products"
Only with quality can we have market, go further, and strive for the quality management concept of survival with quality.
2. Professional production technology management ability.
Pay attention to the process quality control, important performance test and appearance inspection of each work station in the production process. Check the quality level by level.
All staff participate, strengthen management, keep improving and casting quality.
3. Professional technical and after-sales service team
Provide professional technical support and analysis for customers, follow-up before and after orders step by step.
Professional after-sales customer service personnel and online staffing.
FAQ:
Q: Where is your factory ? Can we visit your factory?
A: Our factory is located in Ningbo City, Zhejiang Province,China, 17kms away from Ningbo Airport. We sincerely welcome customers to visit our company and factory.
Q: Could you add our logo on your products?
A: Yes,if your quantity more than 50pcs. we could add your logo on the products.
Q: How long is your delivery time?
A: Generally it is 1-2 days if the goods are in stock. or it will be 3-5 weeks if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ?
A: Yes, we could offer the sample for free charge, but do not pay the cost of express freight.
Q: What is your payment term and payment way?
A: Payment<=2000USD, 100% in advance.
Payment>=2000USD, 30% T/T in advance ,balance before shippment. Payment ways are : T/T, Western Union, Paypal, Alipay.
Q. What’s the shipping way?
A: For small packages, we will choose the door to door express, we cooperated with UPS,DHL,FEDEX,TNT more than 10 years,we gurantee the shipping cost that we offer to you will be the most favorable price among so many suppliers in China. We will send you the tracking number once we got it.
For big orders, By Air or By Sea through your shipping forwarder is acceptable, if you don't have forwarder in China, we will find the most cost-effective one for you.
